The Hayward MaxFlo VS 500 is a compact variable speed pump designed for standard residential pools. Its small footprint, simplified controls, and up to 8 custom speed/timer functions make it an ideal upgrade from single-speed pumps.
| Motor | |
|---|---|
| Type | TEFC |
| Technology | Permanent Magnet |
| Electrical | |
| Voltage | 230 VAC, 60 Hz |
| Phase | Single |
| Max Amps | 10.0A |
| Breaker Size | 15A |
| Performance | |
| Min Speed | 600 RPM |
| Max Speed | 3450 RPM |
| Physical | |
| Dimensions | 9.7 x 9.7 x 11.2 in (W x D x H) |
| Warranty | |
| Standard Warranty | 3 years |
| Part | Part Number | Description |
|---|---|---|
| Strainer Cover Kit | SPX2300DLS | Cover, lock-ring, and O-ring |
| Strainer Cover O-Ring | SPX2300Z4 | Lid O-ring gasket |
| Strainer Basket | SPX2300M | Pump strainer basket |
| Strainer Housing | SPX2300AA | Housing with drain plugs |
| Drain Plug | SPX4000FG | Drain plug with O-ring (qty 2) |
| Diffuser | SPX2300B | Pump diffuser |
| Diffuser O-Ring | SX220Z2 | Diffuser O-ring |
| Impeller | SPX2710CM | Pump impeller |
| Housing O-Ring | GMX600F | Housing O-ring |
| Shaft Seal | SPX2700SAV | Shaft seal assembly, viton |
| Seal Plate | SPX2300E | Pump seal plate |
| Motor Support | SPX2300G | Motor support with base mount screws |
| Union Connector Kit | SPX2700UNKIT | 2 nuts, connectors, gaskets |
| Digital Control Interface | SPX3200LCD | Control display assembly |
| Wall Mount Kit | SPX3400DRKIT | Display wall mount kit |
| Power End Assembly | SPX2303Z1VSPE | Includes motor, drive, and wet end internals |
