The Hayward Super Pump VS 700 is built on the legendary Super Pump platform. It provides a path to energy code compliance while maintaining the plumbing compatibility that made the Super Pump one of the most installed pool pumps in history.
| Motor | |
|---|---|
| Type | TEFC |
| Technology | Permanent Magnet |
| Electrical | |
| Voltage | 230 VAC / 115 VAC |
| Performance | |
| Min Speed | 600 RPM |
| Max Speed | 3450 RPM |
| Warranty | |
| Standard Warranty | 2 years |
| Part | Part Number | Description |
|---|---|---|
| Strainer Cover | SPX1600D | Pump strainer cover |
| Cover Gasket | SPX1600S | Strainer cover gasket |
| Strainer Basket | SPX1600M | Pump strainer basket |
| Drain Plug | SPX4000FG | Drain plug with gasket (qty 2) |
| Strainer Housing | SPX1620AA | Pump/strainer housing |
| Diffuser Gasket | SPX1600R | Diffuser gasket |
| Diffuser | SPX2600B | Pump diffuser |
| Seal Assembly | SPX1600Z2 | Shaft seal assembly |
| Housing Gasket | SPX1600T | Housing gasket |
| Seal Plate | SPX2600E5 | Pump seal plate |
| Hand Knob | SPX1600P | Hand knob (qty 2) |
| Swivel Nut | SPX1600N | Swivel nut (qty 2) |
