The Pentair IntelliFlo VS+SVRS is the speed-only (non-flow) version of the IntelliFlo variable speed pump with built-in Safety Vacuum Release System. While now largely replaced by newer models, the VS+SVRS remains widely installed and commonly serviced.
| Motor | |
|---|---|
| Horsepower | 3.95 THP |
| Type | TEFC |
| Technology | Three-phase six-pole |
| Electrical | |
| Voltage | 230 VAC |
| Phase | Single |
| Performance | |
| Min Speed | 1100 RPM |
| Max Speed | 3450 RPM |
| Max Flow (GPM) | 174 GPM |
| Physical | |
| Dimensions | 23.4 x 10.8 x 12.5 in |
| Certifications | |
| Energy Star | Yes |
| Part | Part Number | Description |
|---|---|---|
| Strainer Basket | 070387 | Hair and lint strainer basket |
| Drain Plug | 071131 | Drain plug (qty 2) |
| Lid O-Ring | 350013z | Strainer cover O-ring |
| Diffuser Assembly | 072928 | Pump diffuser |
| Impeller | 073131 | WFE 12 1000 series impeller |
| Motor | 350105 | VFD Motor 3.2KW PMSM |
| Drive | 351700 | IntelliFlo VS Drive |
